Focal Length 35mm F/1.0 LWIR Athermal Lens For 640X512-12um

loading

Share to:
pinterest sharing button
twitter sharing button
telegram sharing button
linkedin sharing button
wechat sharing button
whatsapp sharing button
facebook sharing button
sharethis sharing button
  • Focal Length: 35mm

  • Aperture: F/1.0

  • LWIR Technology: Long-Wave Infrared

  • Resolution: Compatible with 640x512-12um sensors

  • Athermal Design: No manual focus needed

  • Applications: UAVs, security, surveillance, industrial inspection

Availability:
  • RSA35F1.0-640-12

  • Rising


35mm F/1.0 LWIR Athermal Infrared Lens – High-Performance Thermal Imaging Optics

The 35mm F/1.0 LWIR athermal infrared lens is a premium optical solution built for thermal imaging cameras that use 640×512 resolution, 12µm pixel pitch detectors. With a large F/1.0 aperture and an advanced athermal design, this infrared camera lens ensures high sensitivity, sharp focus, and stable imaging performance across extreme environments.


Key Advantages of the 35mm F/1.0 LWIR Infrared Lens

Exceptional Thermal Sensitivity

The fast F/1.0 aperture maximizes energy capture, delivering bright and detailed infrared images even under low signal conditions.


Athermal Stability in Harsh Environments

Designed as a no-refocus LWIR athermal lens, it maintains precise focus across a wide operating temperature range (–40 °C to +80 °C).


Compact and Lightweight Design

Measuring only 44 × 44.8 mm and weighing just 88 g, this thermal imaging lens is ideal for portable devices, UAV systems, and compact infrared cameras.


High Optical Transmission

With >90% average transmittance in the LWIR band and optional AR coatings, the lens guarantees clear, high-contrast results with long-lasting durability.


Applications

Medical Thermal Imaging

Supports non-contact patient monitoring, temperature screening, and diagnostic imaging, making it valuable for healthcare and medical research.


Security & Surveillance

Reliable infrared camera optics for perimeter protection, 24/7 surveillance, and critical infrastructure defense, even in complete darkness.


Industrial Infrared Inspection

Enhances predictive maintenance, machinery fault detection, and electronics testing by delivering precise long-wave infrared data.


Unmanned Systems & Drones

A lightweight choice for UAV-mounted infrared sensors, robotic vision, and field-deployed thermal imaging solutions.



Technical Highlights

  • Focal Length: 35 mm

  • Aperture: F/1.0

  • Detector Compatibility: 640×512 / 12µm

  • Field of View (FOV): 12.5° × 10.0° × 15.9°

  • Focus Range: 1 m to infinity

  • Mount Interface: M34×0.75-6g

  • Dimensions / Weight: 44 × 44.8 mm / 88 g

  • Operating Temperature: –40 °C to +80 °C


Upgrade your infrared imaging system with the 35mm F/1.0 LWIR athermal lens. Whether applied in medical thermal imaging, industrial infrared inspection, or advanced security surveillance, this lens delivers accuracy, stability, and unmatched optical performance for mission-critical applications.


35mm athermal lens
