LWIR Uncooled Double-FOV Lens Catalog

Share to:

Availability:



Inquire

Product Description

Dual-FOV Lens

Rising Dual-FOV technology enhances imagingversatility by offering two optional fields ofview,enabling precision and adaptability in variousapplications.

Model (Click to see the details)	Focal Length	F#	Detector	Circular FOV
RS60&20F1.2&1.0	20/60MM	1.0/1.2	640x512-12UM	21.74°x17.46°/7.32°x5.86°
RS60&25F1.2&0.9	65/20MM	1.2/0.9	640x512-17UM	10.36°x8.3°/24.55°x19.75°
RS70&25F1.1&0.95	25/70MM	0.95/1.1	1024X768-12UM 640X512-17UM 640X512-12UM	21.61°x20.89°/10.03°x7.53° 24.55°x19.75°/8.89°x7.12° 17.46°x14.01°/6.28°x5.03°
RS75&25F1.0&0.8	25/75MM	0.8/1.0	640X512-17UM 640X512-12UM	24.55°x19.75°/8.3°x6.64° 17.46°x14.01°/5.86°x4.69°
RS88&29.2F1.0&0.88	29.2/88MM	0.88/1.0	640X512-12UM	14.98°x12.01°/5°x4°
RS90&25F1.2&1.0	25/90MM	1.0/1.2	640X512-17UM	24.55°x19.75°/6.92°x5.54°
RS120&40F1.2&0.9	120/40MM	1.2/0.9	640X512-17UM	5.19°x4.15°/15.49°x12.42°
RS132&44F1.1&1.0	44/132MM	1.0/1.1	640X512-17UM	14.1°x11.3°/4.72°x3.78°
RS150&40F1.2&1.0	40/150MM	1.0/1.2	1024X768-12UM 640X512-17UM 640X512-12UM	17.46°x13.14°/14.69°x3.52° 15.49°x12.42°/4.15°x3.32° 10.97°x8.78°/2.93°x2.35
RS150&50F1.2&1.0	50/150MM	1.0/1.2	640X512-12UM	8.78°x7.03°/2.93°x2.35°
RS180&60F1.2&0.9	60/180MM	0.9/1.2	640X512-17UM 640X512-12UM	10.36°x8.3°/3.46°x2.77° 7.32°x5.86°/2.44°x1.96°
