FL 50mm F0.8 LWIR ZnSe Lens For 1024-768-17um

Features of Infrared Lens:

Rising bridges the gap between customers' excellent performance of high precision optical components and limited budget. Remarkably we specialize in the design and manufacture of a wide range of thermal infrared lenses (IR lenses including LWIR, MWIR, and SWIR) for various applications around the globe with superior quality.

Infrared Germanium Lens Application:

1. Airborne

2. Security & Surveillance

3. Maritine & Naval Surveillance

4. Thermography

5. Thermal Imaging Devices(Portable)

6. Defense

7. Enhanced Vision

Infrared Manual Focus Lens Parameters:

Focal Length	50mm
F#	0.8
Wavelength	8-12um
Image Diagonal	21.76mm
Detector	1024x768-17um
Average Transmission	＞86%
Circular FOV	(H)19.7°x(V)14.8°x(D)24.5°
Back Focus Distance	20mm
Back Working Distance	14mm
Back Focus Length	37.75mm
Dimensions	92mm / 74.61mm
Focus Type	Manual Focus
Focus Range	3m to infinity
Mount Type	M55x1-6g
Weight	778g
Operating Temperature	-40℃ to +80℃
Storage Temperature	-40℃ to +80℃
External Coating	AR Coating Available

Infrared Lenes Processing Equipment:

1. Inner carving test platform;

2. Microscope;

3. Opto Tech aspheric processing;

4. Polishing machine;

5. Thickness Gauge;

6. Ultrasonic Cleaner;

7. Workshop;

8. Interferometer;

9. High and low tempera ture test chamber;

10. High polishing machine;

11. Optical bench;

12. Raul milling;

13. Atomic force microscope;

14. Centralinstrument;

15. Hand Grinding and Polishing Machine;

What Materials Are Suitable For Infrared Lenses?

When designing infrared optical components, various factors related to the optical materials used must be considered. These factors include refractive properties, optical transmission, non-thermal properties, hardness/durability, environmental sensitivity, weight/density, manufacturing technology, and cost. Some of these factors are still interrelated. For example, for some materials, their optical transmittance is high at room temperature, but decreases at higher temperatures. Considering all these factors, when designing infrared optical components, careful consideration of material selection is required. Available materials are: silicon (Si), gallium arsenide (GaAs) and cadmium telluride (CdTe); zinc compounds, such as zinc sulfide (ZnS) and zinc selenide (ZnSe); water-soluble crystals, such as Potassium bromide (KBr), sodium chloride (NaCl) and potassium chloride (KCl); fluorides such as magnesium fluoride (MgF2), calcium fluoride (CaF2) and barium fluoride (BaF2); and other materials, Such as fused silica and sapphire; chalcogenide glass, etc.
